Saab 96 1.5 V4 (68 Hp) 1977, 1978, 1979, 1980
Saab 96 1.5 V4 (68 Hp) 1977, 1978, 1979, 1980
Compare

General information

Name

Saab 96 1.5 V4 (68 Hp) 1977, 1978, 1979, 1980

Brand

Saab
Model

96
Generation

96
Year of production

1977

Number of seats

5

Number of doors

2

Body type

Sedan
Powertrain architecture

Internal Combustion engine
Engine Modification

1.5 V4 (68 Hp)

Power

68 Hp @ 4700 rpm.

Torque (Nm)

115 Nm @ 2500 rpm.

Electrical System

Performance specs

Engine specs

Engine #1

Engine code
Ford V-4
Power
68 Hp @ 4700 rpm.
Power per litre
45.4 Hp/l
Torque
115 Nm @ 2500 rpm.
Engine displacement
1498 cm3
Number of cylinders
4
Position of cylinders
V-engine
Cylinder bore
90 mm
Piston stroke
58.86 mm
Compression ratio
9
Fuel system
Carburettor
Fuel type
Petrol (Gasoline)

Space volume and weights

Curb weight (kg)

930 kg

Fuel tank capacity (l)

38 l

Dimensions

Length (mm)

4300 mm

Width (mm)

1590 mm

Height (mm)

1470 mm

Wheelbase (mm)

2500 mm

Front track (mm)

1240 mm

Rear track (mm)

1230 mm

Drivetrain brakes and suspension specs

Drivetrain architecture

The ICE drives the front wheels of the vehicle.

Drive wheel

Front wheel drive

Transmission type

manual

Front brakes

Disc

Rear brakes

Drum

Front tires size

155/80 SR15

Rear tires size

155/80 SR15

Wheel rims size

4.5 x 15
